SHRI RAM POLE INDUSTRIES Businesses wide extend of octagonal manufactured posts utilizing premium quality crude materials that are customized to client specification. We moreover utilize high-strength steel sheet and can deliver single-piece posts up to a length of 12.5 meters or customers’ detail. These posts are fundamentally utilized as road lightning posts or for Moo Voltage Control Dissemination projects. The in-house advanced galvanizing offices guarantee awesome erosion resistance. X-ray, ultrasound and surface-crack reviews guarantee beat fabric quality maximizing the life of NS Shafts & Pole .The entryway opening of the octagonal post is vandal safe and climate verification to guarantee security of inside associations and the welders are well qualified for welding octagonal shafts. The shaft fabricating and galvanizing units are ISO 9001 :2008 certified guaranteeing reliable quality. Octagonal galvanized posts of statures 3 to 12.5 M.
DIAMETER OF OCTAGONAL POLE
MTR | TOP DIA | BOTTOM DIA | THICKNESS | BASE PLATE |
---|---|---|---|---|
4MTR | 70MM | 130MM | 3MM | 200X200X12MM |
5MTR | 70MM | 130MM | 3MM | 200X200X12MM |
6MTR | 70MM | 130MM | 3MM | 220X220X12MM |
7MTR | 70MM | 130MM | 3MM | 220X220X12MM |
8MTR | 70MM | 130MM | 3MM | 220X220X12MM |
9MTR | 70MM | 130MM | 3MM | 220X220X12MM |
9MTR | 70MM | 155MM | 3MM | 260X260X16MM |
10MTR | 70MM | 175MM | 3MM | 275X275X16MM |
10MTR | 90MM | 200MM | 3MM | 300X300X16MM |
